GDS-1000A-U Series User Manual
16
Utility key Utility Configures the Hardcopy function
(page 115), shows the system
status (page 107), selects the menu
language (page 107), runs the self
calibration (page 131), configures
the probe compensation signal
(page 132), and selects the USB
host type(page 104).
Help key Help Shows the Help contents on the
display (page 46).
Autoset key Autoset Automatically configures the
horizontal, vertical, and trigger
settings according to the input
signal (page 48).
Measure key Measure Configures and runs automatic
measurements (page 55).
Save/Recall key Save/Recall Saves and recalls images,
waveforms, or panel settings
(page 109).
Hardcopy key Hardcopy Stores images, waveforms, or
panel settings to USB (page 115).
Run/Stop key Run/Stop Runs or stops triggering (page 50).
Trigger level knob
LEVEL
TRIGGER Sets the trigger level (page 96).
Trigger menu key MENU Configures the trigger settings
(page 96).
Single trigger key SINGLE Selects the single triggering mode
(page 103).
Trigger force key FORCE Acquires the input signal once
regardless of the trigger condition
at the time (page 103).
