GDS-1000A-U Series User Manual

30

Math key 2/2 (FFT/FFT rms)

Operation

FFT

Source

CH1

Zoom

1X

0.0000Hz

1/2/5/10/20X

Window

Hanning

Flattop/
Rectangular/
Blackman/
Hanning

CH1/2

MATH

-12div ~ +12div
20/10/5/2/1 dB

CH1+CH2
CH1-CH2
CH1xCH2
FFT
FFT rms

Vertical

2V

0.00 Div

Math on/off

Math

Select math operation type (+/–
/x/FFT/FFT rms)

Operation

Select FFT source channel

Source

Select FFT window

Window

Select FFT result position

Vertical→VAR
Select vertical scale

Vertical→VOLTS/DIV

Select vertical units

Vertical

Select Zoom level

Zoom(X)→VAR

Select Horizontal position

Zoom(Hz)→VAR
