GETTING STARTED

15

Panel Overview

Front Panel

LCD
Display

Function
keys

VARIABLE
knob

Menu keys

Trigger
LEVEL knob

Trigger
keys

Ground
Terminal

CH1
terminal

USB port

CH2
terminal

Probe
compensation
output

EXT TRIG
terminal

Power
switch

Horizontal
POSITION
knob

Horizontal
MENU key

TIME/DIV
knob

CH1/CH2/
MATH keys

Vertical
POSITION
knob

VOLTS/DIV
knob

VOLTS/DIV

VOLTS/DIV

TIME/DIV

CH 1

MATH

CH 2

MENU

MENU

Acquire

Display

Utility

Help

Run/Stop

VARIABLE

FORCE

Autoset

Cursor

SINGLE

Hardcopy

Measure

Save/Recall

LEVEL

VERTICAL

HORIZONTAL

TRIGGER

CH1

CAT

300V

M

W

15pF

MAX. 300Vpk

1

CH2

EXT TRIG

CAT

300V

M

W

15pF

MAX. 300Vpk

1

X

Y

150 MHz 1 G Sa/s

Digital Storage Oscilloscope

GDS-1152A-U

LCD display

TFT color, 320 x 234 resolution, wide angle view
LCD display.

Function keys:
F1 (top) to
F5 (bottom)

Activates the functions which
appear in the left side of the LCD
display.

Variable knob

VARIABLE

Increases or decreases values and
moves to the next or previous
parameter.

Acquire key

Acquire

Configures the acquisition mode
(page 78).

Display key

Display

Configures the display settings
(page 83).

Cursor key

Cursor

Runs cursor measurements (page
61).

(Continued on next page)
