GDS-1000A-U Series User Manual

24

Q

UICK REFERENCE

This chapter lists the oscilloscope menu tree,
operation shortcuts, built-in help coverage, and
default factory settings. Use this chapter as a
handy reference to access the oscilloscope
functions.

Menu Tree and Shortcuts

Conventions

Examples

Normal

= Press the functional key for “Normal”

Average

= Repeatedly press the functional key for
“Average”

Normal ~ Average

= Select a menu from “Normal” to “Average” and

press its functionality key

Normal→VAR = Press the functionality key for “Normal”, and

then use the Variable knob
