Display key, Autoset key, Hardcopy key – GW Instek GDS-1000A-U Series User Manual User Manual
Page 27
QUICK REFERENCE
27
Display key
Vectors/ Dots
Type
Vectors
On/ Off
Accumulate
Off
Refresh
Contrast
Full
/ /
Display
Select waveform type
Type
Waveform accumulate On/Off
Accumulate
Refresh accumulation
Refresh
Set display contrast
Contrast→VAR
Select display grid
Autoset key
Undo
Type
Fit Screen
Fit Screen
AC Priority
Autoset
Automatically find the signal and set
the scale
Autoset
Change the Type of Autoset mode.
Type
(available for a few seconds)
Undo Autoset
Undo
(available for a few seconds)
Hardcopy key
Hardcopy
→
See Utility key (page 40)
