GDS-1000A-U Series User Manual
76
5. Press Save repeatedly to log
data or screen images.
Save
Waveform
6. Press Interval and use the
Variable knob to select the
interval time.
Source
W 01
VARIABLE
Interval
time 2 secs~ 2min (duration = 5 min)
2 secs~ 5 min (duration 5~ 30 min)
2 secs~ 30 min (duration 30+ min)
7. Press Duration and use the
Variable knob to set the
duration time.
Duration
5 mins
VARIABLE
Duration 5 mins ~ 100 hours
8. Press Previous menu to
return to the Data logging
menu. Data logging is now
ready to begin.
Previous
Menu
