CONFIGURATION

105

Remote Control Interface

The Remote control interface section describes how to set up the
USB interface for PC connection. Remote control command details
are described in the GDS-1000A-U Programming Manual.

USB connection PC / Printer end

Type A, host

GDS-1000A-U end

Type B, slave

Speed

1.1/2.0 (full speed)

Procedure

1. Connect the USB cable to

the USB slave port.

2. The USB port may need to

be configured if the USB
port is not automatically
detected.

page 104

3. When the PC asks for the USB driver, select

dso_cdc_1000.inf (Windows XP) or
dso_vista_cdc.inf (Vista 32bit) which are
downloadable from the GW website,

www.gwinstek.com

, GDS-1000A-U product

corner.

4. On the PC, activate a terminal application such

as Hyper Terminal. To check the COM port
No., see the Device Manager in the PC. For
WindowsXP, select Control panel → System →
Hardware tab.
