Disadvantage: The waveforms
(templates) have to be stored
internally prior to this selection.

Auto

Creates the upper and lower
boundary (template) from the
source signal, not from an
internally stored waveform.
Advantage: No need to store the
waveforms prior to this selection.
Disadvantage: The template shape
is proportional to the source
signal. The distance (allowance)
between the source signal and the
upper and lower template is the
same.

Max/Mix

1. The template is based on the source signal.

Ensure the source signal appears on the
display.

2. Press the Utility key.

Utility

3. Press the More key.

More

4. Press the Go-NoGo Menu

key.

Go-NoGo

Menu

5. Press the Template Edit key.

Template

Edit

6. Press Template repeatedly to

select the upper (Max) or
lower (Min) boundaries.

Template

Max
