GDS-1000A-U Series User Manual

104

Rear Panel USB Port Interface

The USB slave port on the rear panel can be set to auto detect,
however occasionally the USB host type cannot be detected. The
USB Port function allows the USB host type to be manually or
automatically set for the rear panel.

USB connection PC / Printer end

Type A, host

GDS-1000A-U end

Type B, slave

Speed

1.1/2.0 (full speed)

Procedure

1. Connect the USB cable to

the USB slave port on the
GDS-1000A-U.

2. Insert the other end of the

USB cable into the PC or
Printer USB port.

3. Press the Utility key.

Utility

4. Press More twice.

More

x2

5. Press USB Port repeatedly to

set the host device .

USB Port

Auto Detect

Range

Printer, PC, Auto Detect
