GDS-1000A-U Series User Manual

100

7. Press Coupling repeatedly to

select the trigger coupling,
DC or AC.

Coupling

AC

Range

DC, AC

8. Press Rejection to select the

frequency rejection mode.

Rejection

Off

Range

LF, HF, Off

9. Press Noise Rej to turn the

noise rejection on or off.

Noise Rej

Off

Range

On, Off

10. Press Previous menu to go

back to the previous menu.

Previous

Menu

Configuring the video trigger

Procedure

1. Press the Trigger menu key.

MENU

2. Press Type repeatedly to

select video trigger. The
video trigger indicator
appears at the bottom of the
display.

Type

Video

3. Press Source repeatedly to

select the trigger source
channel.

Source

CH1

Range

Channel 1, 2
