MEASUREMENT

69

Edit: NoGo Violation Conditions

Procedure

1. Press the Utility key.

Utility

2. Press the More key.

More

3. Press the Go-NoGo Menu

key.

Go-NoGo

Menu

4. Press Violating repeatedly to

select the NoGo conditions.

Violating

Stop

Stop

Stops the test when the NoGo
conditions have been met.

Continue

The tests continue even when the
NoGo conditions have been met.

Edit: Template (boundary)

Background

The NoGo template sets the upper and lower
amplitude boundary. Two methods are available:
Min/Max and Auto.

Min/Max

Selects the upper boundary (Max)
and lower boundary (Min) as
separate waveforms, from the
internal memory. The upper
boundary is saved to Ref A, the
lower boundary is saved to Ref. B.
Advantage: The template shape
and distance (allowance) between
the source signal are fully
customizable.
