Utility key 9/11 (Data Logging 1/2)
Off
CH1/CH2
On/Off
To previous
menu
Data logging
Data logging
Source
CH1
Setup
File
Utilities
Previous
Menu
(USB only)
To File Utilities
To the Edit
menu
Turn Data Logging On/Off
Data logging
Set the logging source
Source
Go to the Data Logging Edit menu
Setup
Go to the File Utilities menu
File Utilities
Go back to previous menu
Previous Menu
Utility key 10/11 (Data Logging 2/2)
2 secs~30 mins
Waveform/Image
To previous
menu
Edit
Save
Waveform
Interval
2 secs
Duration
5 mins
Previous
Menu
5 mins~100 hrs
Save the logs as waveform data or
as image files
Save
Set the logging interval
Interval→VAR
Set the duration of the record log
Duration→VAR
Go back to previous menu
Previous Menu
Utility key 11/11 (Self CAL Menu)
Vertical
Self Cal.
Start Vertical
Calibration
Start Vertical Calibration
