MEASUREMENT
67
10. To move the FFT/FFT rms
waveform horizontally,
press Zoom repeatedly until
Hz is selected. Use the
Variable knob to change the
horizontal position.
Zoom
1X
0.0000Hz
VARIABLE
Range 0~50.000MHz
11. To clear the FFT result from
the display, press the Math
key again.
MATH
Go No-Go Testing
Overview
Background Go-NoGo testing checks if a waveform conforms to
a user-specified maximum and minimum
boundary (template). The testing can be set to stop
or continue each time the template has or has not
been violated by the input waveform.
Settings Item Default Details
NoGo criteria: When inside
or outside the boundary Inside Page 68
Source Channel 1 Page 68
Test continue or stop when
NoGo occurs Stop Page 69
Boundary (template) –
selects the minimum and
maximum boundaries
(template) from a single
waveform Auto (0.4%) Page 69
Run Tests Page 73
