CONFIGURATION
83
Display
The Display section describes how to configure the display settings:
drawing type, waveform accumulation, contrast adjustment, and
grid settings.
Selecting vector or dot drawing
Procedure 1. Press the Display key. Display
2. Press Type repeatedly to
select the waveform
drawing.
Type
Vectors
Types Dots Only the sampled dots are displayed.
Vectors The sampled dots are connected by
lines.
Accumulating the waveform
Background Accumulation preserves the old waveform
drawings and overwrites new waveforms on top
of it. It is useful for observing waveform variation.
Procedure 1. Press the Display key. Display
2. Press Accumulate to turn on
the waveform accumulation.
Accumulate
On
3. To clear the accumulation
and start it over (refresh),
press Refresh. Refresh
