5.2.2 The Select Push-buttons
Located below the text display screen, these three push-buttons,
allow you to select from the pre-defined options appearing on the
display screen. The following example illustrates the use of the select
push-buttons:
If the text on the screen appeared as follows:
a. By pressing S1 the gas concentrations which appear in the
measurement results will be quoted in mg/m 3 .
b. By pressing S3 the gas concentrations which appear in the
measurement results will be quoted in ppm.
5.2.3 Function Push-buttons
The order of these push-buttons are the same as they are seen on
the front of the monitor.
RESET By pressing this push-button you can choose the type of
reset the Monitor should perform. For further details see
section 5.3 .
LOCK This push button enables setting up three different
password protected User Levels. For further details see
section 2.7 .
MEASURE In this mode you are able to choose the type of
measurement the Monitor should perform, and decide
when the measurement should start.
MEMORY In this mode you are able to store measurement data in
the Background memory of the monitor, as well as recall
or delete data from the Background memory.
INFO This push-button has two functions. It allows you to
perform the following two functions:
SELECT CONCENTRATION UNIT
mg/m 3 ppm
