Chapter 10
______________________________________________________________________
_____________________________________________________________________________
BE6030-13 1314i Photoacoustic Gas Monitor LumaSense Technologies A/S
Page 118 of 199
3. When you have been through all the parameters, the monitor
returns to the top of the Communication branch of the Set-Up
Tree.
4. Press S3 S1 and then SET-UP. This selects the RS-232 port as
the communication port for the printer.
5. Press RESET and S1 to partially reset your Monitor.
10.3.2 Ethernet Interface
From the top of the Communication branch of the Setup Tree
SELECT COMMUNICATION SET-UP BRANCH
RS 232 C ADDRESSABLE CONNECTIONS
1. Press S2. (ADDRESSABLE)
2. Please refer to section 2.5 how to setup the Ethernet parameters.
3. When you have been through all the Ethernet parameters, press
SET-UP and then S3 S1 S3 S3 S3 and finally SET-UP. This
selects the Ethernet port as the communication port for the
printer.
Press RESET and S1 to partially reset your Monitor.
On the remote PC you can now prepare an Ethernet terminal
program like HyperTerminal to be able to receive the printed output
from the gas monitor.
HyperTerminal is a terminal program able to receive Ethernet
communication send from the gas monitor.
