5.15 Triggering
Triggering Options can be set in both Simple and Advanced Modes. The options in both
modes are the same, only the GUI is different where shortcuts for the events are
displayed in the Simple Mode for easy access (see
Figure 5.2 on page 49 ).
In the Advanced Mode triggering is set up via the recording rules which allow greater
flexibility to create advanced sequences you would like the analyzer to look for. These
recording rules are not available in the Simple Mode. The Simple Mode allows you to
simply define triggering by checking the boxes.
Note:
Ensure that the correct analyzer is selected for the right options.
5.15.1 Triggering On (Simple Mode)
You can check any of the boxes shown in Table 5.1 for Trigger On in Simple Mode (see
Figure 5.14 on page 60 ).
Trigger Position is only available when Event Trigger or Bit Tracer Recording is selected.
Note: If you check 2 boxes or more the triggering will occur based on an OR condition, not AND
condition.
Note: External Input Trigger is not configurable, it will always cause the analyzer to trigger on a toggle
when using manual trigger or triggering on any event.
TABLE 5.1: Simple Mode Trigger On Events
Enter Elec Idle AnyTLP
Exit Elec Idle Config
Switch to G1 Memory
Switch to G2 IO
TS1 RD Error
TS2 Invalid Symbol
InitFC1 Block Align Error
NAK Token Error
PM Idle Symbol Error
