Chapter 8
Display Options
8.1 Setting
Display
Options
Display Options allow you to customize the colors and formats of displayed traffic.
To open the Display Options dialog at the General tab, Select Setup > Display Options
from the menu or
click the Display Options button
on the toolbar.
Figure 8.1: Display Options Dialog - General Tab
