Teledyne LeCroy Using the Menus
28 Summit T24 PCI Express Multi‐Lane Protocol Analyzer User Manual
4.5.4 Report Menu
Report Menu operations are only available when you are working with a CATC Trace file.
File
Information Displays information about the file contents and describes the
conditions of the file’s recording (Recording Options, hardware
information, and so on).
Error Summary Displays an error summary of the current CATC Trace file and allows
you to go to a specific packet, and save the error file to a uniquely
named file.
Traffic
Summary Details the number and types of packets that were transferred
during the recording. You can hide, save, send, text, print, and view.
Bus Utilization Opens a window with graphs of bus usage for the open CATC Trace.
Link Tracker Opens a window for displaying a detailed chronological view of
traffic. The window provides view and navigation options.
Data Flow Opens the Data Flow Window, providing a tabular view of
transactions and their payload.
Trace
Navigator Shows the Navigator bar for navigating a CATC Trace. Shows a
snapshot of the recording and allows you to adjust the memory
area for the view.
LTSSM Flow
Graph Shows a state diagram of bus activity. Also allows you to navigate
through the LTSSM, based on the current recording.
Packet Header Opens the Packet Header bar, showing the Packet Header
information as it would be viewed in the specification.
Packet Data Opens the Data Window for the current packet or transaction, with
the options: Hide, Save, Hexadecimal, ASCII, Decimal, Binary,
MSB Format, LSB Format, Big Endian, and Little Endian. Format Line
allows you to enter the number of bytes, words, or dwords per line.
Configuration
Space Presents a list of Configuration Spaces. Clicking an item displays the
selected Configuration Space in a Configuration Table format.
