Summit T24 PCI Express Multi‐Lane Protocol Analyzer User Manual 29
Using the Menus Teledyne LeCroy
4.5.5 Search Menu
Search Menu operations are only available when you are working with a CATC Trace file.
Go to Trigger Repositions the display to show the first packet following the
trigger event.
Go to
Segment/
Packet Repositions the display to a specific packet, Link or Split transaction
of PCI Express protocol or NVME, PQI, AHCI protocol and ATA
command transactions number.
Go to Time Repositions the display to a specific timestamp.
Go to Marker Repositions the display to a previously marked packet, Link, Split,
NVME, PQI, AHCI protocol or ATA command transactions.
Go to Packet Allows searching for specific link events: TLP Type, DLLP Type,
Ordered Set, Link Event, Traffic Class, DLLP Virtual Channel,
TLP Virtual Channel, Direction, Speed, Link Width, Requester ID,
Completer ID, Data Lengths, Errors.
Find Displays the Find dialog to allow searching for various events within
a CATC Trace. You can search by Display Level: Packets, Link or Split
transaction of PCI Express protocol or NVME, PQI, AHCI protocol
Transaction
You can search packets by Event Group: TLP Type, TLP Header,
TLP Requester ID, TLP Completer ID, TLP Data Pattern,
TLP Data Lengths, TLP Tag, TLP Sequence Number, DLLP Type,
DLLP Header, DLLP Virtual Channel, ACK/NAK Seq Number,
Ordered Sets, Link Event, Direction, Errors, TS1 Data, TS2 Data.
You can search link transactions by Event Group: TLP Type,
Traffic Class, Virtual Channel, Direction, Requester ID,
Completer ID, Status, Tag.
You can search split, NVMe and PQI transactions by Event Group:
TLP Type, Traffic Class, Virtual Channel, Direction, Requester ID,
Completer ID, Status, Tag, Address.
You can search AHCI transactions by Event Group:
AHCI Register ID, AHCI Port Number, AHCI Slot Number, AHCI Port
Multiplier Port, Raw Address, AHCI Direction, AHCI Errors.
Find allows you to create complex searches based on numerous
criteria.
Find Next Repeats the previous Find or Search operation.
Search
Direction Allows you to specify a forward or backward search of a CATC Trace
file.
