Teledyne LeCroy Using the Menus
30 Summit T24 PCI Express Multi‐Lane Protocol Analyzer User Manual
4.5.6 View Menu
Toolbars>> Displays available toolbars: Standard, Frequently Used, Analysis,
and Transaction Level. Use Customize to display the Windows
Customize window.
Script Editor Displays the Script Editor (only appears if a .peg file is open).
Analyzer
Network
Chat Bar Opens a chat window for communicating with persons working
with networked Analyzers. This command requires that your host
machine be attached to a LAN. The Chat window broadcasts
messages to whatever hosts have been connected to via the
Analyzer Network command (under Setup in the menu).
Status Bar Switches display of the Status Bar on or off.
CATC Walk Lets you play a playlist or manage Playlists (see “CATC Walk Playlist”
on page 129 ).
Real Time
Statistics Opens the Real Time Statistics monitor dialog and displays a real‐
time graph of link activity.
Zoom In Zoom in increases the size of the displayed elements.
Zoom Out Zoom out decreases the size of the displayed elements.
Wrap Allows the display to wrap.
Synchronize
Trace View
with Other
Views Synchronize the Trace View with Other Views so that a move in one
view repositions the other views.
FC Credits Toggles a display for tracking Flow Control Credit update and
consumption on a PCI Express link.
FC Credits
Setup Allows you to customize the display for tracking Flow Control
Credits.
Compact View Toggles compacting of the Link Training sequence to analyze CATC
Trace data faster or no compacting to display more data.
Packet Level View the current recording at the Packet Level.
Link
Transaction
Level View the current recording at the Link Transaction Level.
Split
Transaction
Level View the current recording at the Split Transaction Level.
