Summit T24 PCI Express Multi‐Lane Protocol Analyzer User Manual 31
Using the Menus Teledyne LeCroy
4.5.7 Tools Menu
4.5.8 Window Menu
NVM
Transaction
Level View the current recording at the NVM Transaction Level.
PQI
Transaction
Level View the current recording at the PQI Transaction Level.
ACHI
Transaction
Level View the current recording at the ACHI Transaction Level.
ATA
Transaction
Level View the current recording at the ATA Transaction Level.
Configuration
Space Editor Displays the Configuration Space Editor dialog which allows you to
either create a new Configuration Space File or open an existing
Configuration Space File.
Memory/IO
Space Editor Displays the Memory/IO Space Editor dialog which allows you to
either create a new Address Space File or open an existing Address
Space File. Select the memory size from the drop‐down menu.
TC to VC
Mapping Allows Traffic Classes to be mapped to Virtual Channels for
purposes of simplifying navigation (for example, Search > Go to >
TLP Virtual Channel) and changing the way the CATC Trace is
displayed (for example, in Split Transactions).
Timing
Calculations Starts the mode‐less calculator dialog for calculating various timing
and bandwidth parameters in the recording file.
PCIe SSD Base
Address
Mapping Presents the PCIe SSD Base Address Mapping dialog.
Run
Verification
Scripts Presents a list of verification scripts, from which you can run a
verification script.
New Window Opens a copy of the current CATC Trace window.
Cascade Displays all open CATC Trace windows in an overlapping
arrangement.
Tile Displays all open CATC Trace windows as a series of strips across the
display.
