4.7.2.8. RS-232 Report Function
The 9110TH/M DAS can automatically report data to the communications ports, where
they can be captured with a terminal emulation program or simply viewed by the user.
To enable automatic COM port reporting, follow the instruction shown in section 4.7.2.2
then press:
Edit Data Channel Menu
SETUP X.X 0) CONC: ATIMER, 8, 800
PREV NEXT INS DEL EDIT PRNT EXIT
Exits to the main
Data Acquisition
menu
SETUP X.X NAME:CONC
SET> EDIT PRINT EXIT
SETUP X.X RS-232 REPORT: OFF
EDIT PRINT EXIT
ENTR accepts the new
setting and returns to the
previous menu.
EXIT ignores the new setting
and returns to the previous
menu.
SETUP X.X RS-232 REPORT: OFF
OFF ENTR EXIT
Toggle button to turn
reporting ON or OFF
Press SET> key until…
From the DATA ACQUISITION menu
(see Section 6.7.2.2)
4.7.2.9. Compact Report
When enabled, this option avoids unnecessary line breaks on all RS-232 reports. Instead
of reporting each parameter in one channel on a separate line, up to five parameters are
reported in one line, instead. For example, channel DIAG would report its record in two
lines (10 parameters) instead of 10 lines. Individual lines carry the same time stamp and
are labeled in sequence.
4.7.2.10. Starting Date
This option allows to specify a starting date for any given channel in case the user wants
to start data acquisition only after a certain time and date. If the Starting Date is in the
past, the DAS ignores this setting.
