Model 9110TH NOx Analyzer Troubleshooting & Repair
Teledyne Analytical Instruments 206
SAMPLE A1:NXCNC1=100PPM NOX=XXX.X
< TST TST > CAL SETUP
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SETUP X.X ENTER PASSWORD:818
8 1 8 ENTR EXIT
DIAG SIGNAL I/O
NEXT ENTR EXIT
DIAG I/O 0) EXT_ZERO_CAL =OFF
NEXT JUMP ENTR EXIT
DIAG I/O JUMP TO:0
0 0 ENTR EXIT
DIAG I/O JUMP TO:7
0 7 ENTR EXIT
DIAG AIO 7) CAL LED=OFF
PREV NEXT JUMP OFF PRNT EXIT
Enter 07 to Jump
to Signal 7:
(CAL_LED)
Toggle to turn the
CAL LED ON/OFF
Figure 7-2: Switching Signal I/O Functions
