Operating Instructions Model 9110TH NOx Analyzer
Teledyne Analytical Instruments 67
4.7.2.1. Viewing DAS Data and Settings
DAS data and settings can be viewed on the front panel through the following keystroke
sequence.
SAMPLE A1:NXCNC1=100PPM NOX=XXX.X
< TST TST > CAL SETUP
SETUP X.X CONC : DATA AVAILABLE
NEXT VIEW EXIT
SETUP X.X CALDAT: DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X CALCHE: DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 285:00:00 SMPFLW= X.XXX cc/m
PV10 PREV PRM> EXIT
SETUP X.X 287:10:00 NXCNC1: XXX.X PPM
PV10 PREV NEXT NX10 PRM> EXIT
SETUP X.X 281:15:10 NXZCS1: X.XXX PPM
PV10 PREV NEXT NX10 PRM> EXIT
SETUP X.X DATA ACQUISITION
VIEW EDIT EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
FRONT PANEL CONTROL BUTTON FUNCTIONS
BUTTON FUNCTION
Moves to the next Parameter
PRM> Moves to the previous
Parameter
NX10 Moves the view forward 10
data points/channels
NEXT Moves to the next data
point/channel
PREV Moves to the previous data
point/channel
PV10 Moves the view back 10 data
points/channels
Buttons only appear if applicable
EXIT will return to the
main SAMPLE Display.
SETUP X.X DIAG: DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 00:00::00 PMTDET=0000.0000 m
PV10 PREV PRM> EXIT
SETUP X.X HIRES : NO DATA AVAILABLE
PREV EXIT
Default
setting for
HIRES is
DISABLED.
