Operating Instructions Model 9110TH NOx Analyzer
Teledyne Analytical Instruments 141
The default settings for this feature are:
Table 4-27: 9110TH/M Concentration Display Default Values
DISPLAY VALUE DISPLAY DURATION
NOX 4 sec.
NO 4 sec.
NO2 4 sec.
O2 4 sec.
1 Only appears if O
2
sensor option is installed.
To change these settings, press:
INSERT adds a new entry on the display list
before the currently selected value.
Toggle PREV and NEXT keys until desired
display value appears.
SAMPLE A1:NXCNC1=100PPM NOX=XXX.X
< TST TST > CAL SETUP
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SETUP X.X ENTER PASSWORD:818
8 1 8 ENTR EXIT
DIAG SIGNAL I/O
NEXT ENTR EXIT
Continue pressing NEXT until ...
DIAG DISPLAY SEQUENCE CONFIG.
PREV NEXT ENTR EXIT
DIAG DISP 1) NOX, 4 SEC
PREV NEXT INS DEL EDIT ENTR EXIT
Moves back and forth
along existing list of
display values
DIAG DISP DISPLAY DATA: NOX
PREV NEXT ENTR EXIT
DIAG DISP DISPLAY DATA: N2H
PREV NEXT ENTR EXIT
DIAG DISP DISPLAY DURATION: 4 SEC
0 4 ENTR EXIT
Toggle these buttons to set desired
display duration in seconds
ENTR Accepts the
new setting.
EXIT discards the
new setting.
