Model 9110TH NOx Analyzer Operating Instructions
Teledyne Analytical Instruments 98
Internet Configuration Button Functions
BUTTON FUNCTION
[0]
Location of cursor. Press to cycle through the range of
numerals and available characters (“0 – 9” & “ . ”)
Moves the cursor one character left or right.
DEL Deletes a character at the cursor location.
ENTR
Accepts the new setting and returns to the previous
menu.
EXIT
Ignores the new setting and returns to the previous
menu.
Some buttons appear only when relevant.
SETUP X.X DHCP: OFF
SET> EDIT EXIT
SETUP X.X INST IP: 000.000.000.000
EDIT EXIT
SETUP X.X GATEWAY IP: 000.000.000.000
EDIT EXIT
SETUP X.X INST IP: [0] 00.000.000
DEL [0] ENTR EXIT
SETUP X.X SUBNET MASK:255.255.255.0
EDIT EXIT
SETUP X.X SUBNET MASK:[2]55.255.255.0
DEL [?] ENTR EXIT
SETUP X.X TCP PORT 3000
EDIT EXIT
The PORT number must remain at 3000.
Do not change this setting unless instructed to by
Teledyne Instruments Customer Service personnel.
SETUP X.X GATEWAY IP: [0] 00.000.000
DEL [?] ENTR EXIT
Cursor
location is
indicated by
brackets
SETUP X.X INITIALIZING INET 0%
…
INITIALIZING INET 100%
SETUP X.X INITIALIZATI0N SUCCEEDED SETUP X.X INITIALIZATION FAILED
SETUP X.X COMMUNICATIONS MENU
ID INET COM1 EXIT
Pressing EXIT from
any of the above
display menus
causes the Ethernet
option to reinitialize
its internal interface
firmware
Contact your IT
Network Administrator
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X COMMUNICATIONS MENU
ID INET COM1 EXIT
DHCP: ON is
default setting.
Skip this step
if it has been
set to OFF.
SETUP X.X DHCP: ON
SET> EDIT EXIT
ENTR
accepts
the new
assigned
numbers;
EXIT
ignores
Figure 4-7: COM – LAN / Internet Manual Configuration
