Operating Instructions

Model 9110TH NOx Analyzer

Teledyne Analytical Instruments

121

To Turn the over-range feature on or off, press:

From the

AIO CONFIGURATION SUBMENU

(See Section 6.13.4.1)

DIAG AIO DATA_OUT_2 5V, NXCNC1, NOCAL

SET>

EDIT

EXIT

DIAG AIO DATA_OUT_2 OVERRANGE: ON

SET>

EDIT

EXIT

DIAG AIO DATA_OUT_2 RANGE: 5V

SET>

EDIT

EXIT

DIAG AIO DATA_OUT_2 OVERRANGE: ON

ON

ENTR EXIT

DIAG AIO DATA_OUT_2 OVERRANGE: OFF

OFF

ENTR

EXIT

DIAG

ANALOG I/O CONFIGURATION

PREV NEXT

ENTR

EXIT

Toggle this button
to turn the Over-
Range feature ON
or OFF

Continue pressing SET> until you reach the

output to be configured

DIAG AIO AOUTS CALIBRATED: NO

SET>

CAL

EXIT

4.13.5.4. Adding a Recorder Offset to an Analog Output

Some analog signal recorders require that the zero signal is significantly different from
the baseline of the recorder in order to record slightly negative readings from noise
