Model 9110TH NOx Analyzer Operating Instructions
Teledyne Analytical Instruments 56
A1:NXCNC1=100 PPM 1
A2:NOCNC1=100 PPM 1
A3:N2CNC1=25 PPM 1
A4:NXCNC2=100% 1
RANGE
NOX STB
SAMP FLW
OZONE FL
PMT
NORM PMT
AZERO
HVPS
RCELL TEMP
BOX TEMP
PMT TEMP
CONV TEMP
O2 CELL TEMP 2
RCEL
SAMP
NOX SLOPE
NOX OFFS
NO SLOPE
NO OFFS
O2 SLOPE 2
O2 OFFS 2
TIME
SAMPLE A1:NXCNC1=100 PPM
1
NOX = XXX
< TST TST >
CAL SETUP
1
Default settings for user
selectable reporting range
settings.
2
Only appears if O
2
sensor
option is installed.
Toggle to scroll
through list of functions
Figure 4-2: Viewing 9110TH/M TEST Functions
Note A value of “XXXX” displayed for any of the TEST functions indicates an
out-of-range reading or the analyzer’s inability to calculate it. All pressure
measurements are represented in terms of absolute pressure. Absolute,
atmospheric pressure is 29.92 in-Hg-A at sea level. It decreases about 1
in-Hg per 300 m gain in altitude. A variety of factors such as air
conditioning and passing storms can cause changes in the absolute
atmospheric pressure.
4.2.2. WARNING MESSAGES
The most common instrument failures will be reported as a warning on the analyzer’s
front panel and through the COM ports. Appendix A provides the recommended action
and explains how to use these messages to troubleshoot problems. 7.1.1 shows how to
view and clear warning messages.
