4.13.5.2. Analog Output Signal Type and Range Selection
To select an output signal type (DC Voltage or current) and level for one output channel
press:
DIAG AIO AOUTS CALIBRATED: NO
SET> CAL EXIT
From the
AIO CONFIGURATION SUBMENU
(See Section 6.13.4.1)
DIAG ANALOG I/O CONFIGURATION
PREV NEXT ENTR EXIT
Continue pressing SET> until you reach the
output to be configured
DIAG AIO DATA_OUT_3: 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO DATA_OUT_3: RANGE: 5V
0.1V 1V 5V 10V CURR ENTR EXIT
These keys set
the signal level
and type of the
selected
channel
Pressing ENTR records
the new setting and
returns to the previous
menu.
Pressing EXIT ignores the
new setting and returns to
the previous menu.
