Model 9110TH NOx Analyzer

Operating

Instructions

Teledyne Analytical Instruments

68

4.7.2.2. Editing DAS Data Channels

DAS configuration is most conveniently done through the APICOM remote control
program. The following sequence of touch screen button presses shows how to edit
using the front panel.

Edit Data Channel Menu

SAMPLE A1:NXCNC1=100PPM NOX=XXX.X

< TST TST > CAL

SETUP

SETUP X.X

0) CONC: ATIMER, 8, 800


PREV NEXT INS DEL EDIT PRNT EXIT

SETUP X.X

DATA ACQUISITION

VIEW

EDIT

EXIT

SETUP X.X

PRIMARY SETUP MENU

CFG

DAS

RNGE PASS CLK MORE

EXIT

EXIT will return to the

previous SAMPLE

display.

SETUP X.X

ENTER DAS PASS: 818


8 1 8

ENTR

EXIT

Moves the

display up &

down the list of
Data Channels

Inserts a new Data

Channel into the list

BEFORE the Channel

currently being displayed

Deletes The Data
Channel currently

being displayed

Exports the

configuration of all

data channels to

RS-232 interface.

Exits to the Main

Data Acquisition

Menu

SETUP X.X

NAME:CONC


EDIT PRNT

EXIT

Moves the display

between the

PROPERTIES for this

data channel.

Reports the configuration of current

data channels to the RS-232 ports.

EXITS returns to

the previous

Menu

Allows to edit the channel name, see next key sequence.

When editing the data channels, the top line of the display indicates some of the
configuration parameters. For example, the display line:

0) CONC : ATIMER, 4, 800

Translates to the following configuration:

Channel No.: 0
NAME: CONC
TRIGGER EVENT: ATIMER
PARAMETERS: Four parameters are included in this channel
EVENT: This channel is set up to record 800 data points.
