Model 9110TH NOx Analyzer Operating Instructions
Teledyne Analytical Instruments 118
5. Set the reporting range scale for the data type chosen.
6. Set the update rate for the channel.
7. Calibrating the output channel. This can be done automatically or manually for
each channel (see Sections 4.13.6).
To access the analog I/O configuration sub menu, press:
AIO Configuration Submenu
SAMPLE A1:NXCNC1=100PPM NOX=XXX.X
< TST TST > CAL SETUP
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SETUP X.X ENTER PASSWORD:818
8 1 8 ENTR EXIT
DIAG SIGNAL I/O
NEXT ENTR EXIT
Continue pressing NEXT until ...
DIAG ANALOG I/O CONFIGURATION
PREV NEXT ENTR EXIT
DIAG AIO A OUTS CALIBRATED: NO
SET> CAL EXIT
DIAG AIO DATA_OUT_1: 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO AIN CALIBRATED: NO
SET> CAL EXIT
DIAG AIO DATA_OUT_2: 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO DATA_OUT_3: 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO DATA_OUT_4: 5V, NXCNC1, NOCAL
SET> EDIT EXIT
