Getting Started

Model 9110TH NOx Analyzer

Teledyne Analytical Instruments

35

Table 3-11: Two-Point Span Valve Operating States

MODE VALVE

CONDITION

SAMPLE

Sample/Cal

Open to SAMPLE inlet

Zero Gas Valve

Closed to ZERO AIR inlet

High Span Valve

Closed to HIGH SPAN inlet

Low Span Valve

Closed to LOW SPAN inlet

ZERO

CAL

Sample/Cal

Closed to SAMPLE inlet

Zero Gas Valve

Open to ZERO AIR inlet

High Span Valve

Closed to HIGH SPAN inlet

Low Span Valve

Closed to LOW SPAN inlet

HIGH

SPAN

CAL

Sample/Cal

Closed to SAMPLE inlet

Zero Gas Valve

Closed to ZERO AIR inlet

High Span Valve

Open to HIGH SPAN inlet

Low Span Valve

Closed to LOW SPAN inlet

Low Span

Check

Sample/Cal

Closed to SAMPLE inlet

Zero Gas Valve

Closed to ZERO AIR inlet

High Span Valve

Closed to HIGH SPAN inlet

Low Span Valve

Open to LOW SPAN inlet
