Model 9110TH NOx Analyzer
Teledyne Analytical Instruments iv
Power Requirements
This Model 9110E is configured to operate from the following AC Power source:
100-120 VAC 60 Hz 220-240 VAC 60 Hz 100V 60 Hz
100-120 VAC 50 Hz 220-240 VAC 50 Hz 100V 50 Hz
Analog Output Signals
Analog output signals are available at A1, A2, and A3 on the rear panel. This instrument is
configured with the following analog outputs:
A1(NOx): 4-20 mA
A2 (NO): 0-5 V
A2(NO): 4-20 mA
A3 (NO
2
): 0-5 V A2(NO
2
): 4-20 mA
Range Mode
The analyzer can be designed with a single or dual analysis ranges with auto-ranging or dual
independent ranges. This analyzer is configured with the following range mode:
Single Range:
Dual Range/Auto-ranging: Dual Range/Independent:
Low Range: Low Range:
High Range: High Range:
Gas:
Selected Options for the Model 9110T
Mounting Options
19” rack mounting with 26” sliders with ears
19” rack mounting with ears only
Pump Mounting Options
None
Rack mounting hardware
Rear Panel Gas Fittings
1/4” SS Standard
6 mm SS Optional
