Operating Instructions Model 9110TH NOx Analyzer
Teledyne Analytical Instruments 125
To assign a DAS parameter to a specific analog output channel, press,
EXAMPLE
From the
AIO CONFIGURATION SUBMENU
(See Section 6.13.4.1)
DIAG AIO DATA_OUT_2 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 DATA: NOCNC1
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 OUTPUT: 5V
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 DATA: STABIL
SET> EDIT EXIT
DIAG ANALOG I/O CONFIGURATION
PREV NEXT ENTR EXIT
Use these buttons to move
up and down the list if
available DAS parameters
(See Table A-6 of Appendix A.5)
Continue pressing SET> until ...
Continue pressing SET> until you reach the
output to be configured
DIAG AIO AOUTS CALIBRATED: NO
SET> CAL EXIT
DIAG AIO DATA_OUT_2 DATA: NOCNC1
PREV NEXT ENTR EXIT
DIAG AIO DATA_OUT_2 DATA: STABIL
INS DEL [1] ENTR EXIT
