4.11.7.1. Configuring Ethernet Communication Using DHCP
1. Consult with your network administrator to affirm that your network server is running
DHCP.
2. Access the Ethernet Menu (SETUP>MORE>COMM>INET).
3. After pressing ENTR at the password menu, press SET> to view the DHCP
settings:
SETUP X.X COMMUNICATIONS MENU
ID INET COM1 COM2 EXIT
SETUP X.X INST IP: 0.0.0.0
SET> EXIT
SETUP X.X GATEWAY IP: 0.0.0.0
SET> EXIT
SETUP X.X TCP PORT2: 502
SET> EDIT EXIT
THE EDIT button is disabled. Each string of octets
should be assigned numbers by the DHCP; if all 0’s,
DHCP failed. Consult your network administrator.
From this point on,
EXIT returns to
COMMUNICATIONS
MENU
Do not alter unless
directed to by Teledyne
Instruments Customer
Service personnel
SETUP X.X HOSTNAME:
EDIT EXIT
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X SUBNET MASK: 0.0.0.0
SET> EXIT
SETUP X.X TCP PORT: 3000
SET> EDIT EXIT
SETUP X.X DHCP: ON
SET> EDIT EXIT
DHCP: ON is
default setting.
If it has been
set to OFF,
press EDIT
and set to ON.
SETUP X.X DHCP: OFF
OFF ENTR EXIT
SETUP X.X DHCP: ON
ON ENTR EXIT
