Operating Instructions Model 9110TH NOx Analyzer
Teledyne Analytical Instruments 129
To change the update rate for an individual analog output channel, press:
EXAMPLE
From the
AIO CONFIGURATION SUBMENU
(See Section 6.13.4.1)
DIAG AIO DATA_OUT_2 5V, NXCNC1, NOCAL
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 UPDATE: 5 SEC
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 OUTPUT: 5V
SET> EDIT EXIT
DIAG AIO DATA_OUT_2 UPDATE: 30 SEC
SET> EDIT EXIT
DIAG ANALOG I/O CONFIGURATION
PREV NEXT ENTR EXIT
Toggle these
buttons to set
the data update
rate for this
channel.
Continue pressing SET> until ...
DIAG AIO DATA_OUT_2 UPDATE: 30 SEC
0 3 0 ENTR EXIT
Continue pressing SET> until you reach the
output to be configured
DIAG AIO AOUTS CALIBRATED: NO
SET> CAL EXIT
DIAG AIO DATA_OUT_2 UPDATE: 5 SEC
0 0 5 ENTR EXIT
