Model 9110TH NOx Analyzer Operating Instructions
Teledyne Analytical Instruments 156
To initialize the modem press:
Select which
COM Port is
tested
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS
RNGE PASS CLK MORE EXIT
SAMPLE A1:NXCNC1=100PPM NOX=XXX.X
< TST TST > CAL SETUP
SETUP X.X COMMUNICATIONS MENU
ID COM1 COM2 EXIT
EXIT returns
to the
previous
menu
SETUP X.X COM1 MODEM INIT:AT Y  &D &H
SET> EDIT EXIT
SETUP X.X COM1 INITIALIZE MODEM
INIT EXIT
SETUP X.X COM1 MODE:0
SET> EDIT EXIT
SETUP X.X COM1 BAUD RATE:19200
SET> EDIT EXIT
EXIT returns to the
Communications Menu.
SETUP X.X INITIALIZING MODEM
INIT
EXIT
4.15.2.7. COM Port Password Security
In order to provide security for remote access of the 9110TH/M, a LOGON feature can
be enabled to require a password before the instrument will accept commands. This is
done by turning on the SECURITY MODE (see Section 4.9). Once the SECURITY
MODE is enabled, the following items apply.
 A password is required before the port will respond or pass on commands.
 If the port is inactive for one hour, it will automatically logoff, which can
also be achieved with the LOGOFF command.
 Three unsuccessful attempts to log on with an incorrect password will cause
subsequent logins to be disabled for 1 hour, even if the correct password is
used.
 If not logged on, the only active command is the '?' request for the help
screen.
 The following messages will be returned at logon:
o
LOGON SUCCESSFUL - Correct password given
o
LOGON FAILED - Password not given or incorrect
o
LOGOFF SUCCESSFUL - Connection terminated successfully
To log on to the 9110TH/M analyzer with SECURITY MODE feature enabled, type:
