S T A N D A R D P R I N T E R C O M M A N D S
Comments MaxiCodes cannot be rotated, and can never have
human-readable subtext.
Example The following example uses the alternate form, with
data coded following the ANSI MH10.8.3 standard.
NOTE: This format will not print if copied directly to the
printer. The
BARCODE UPS command line is broken
for Help window readability. Also, the example uses
non-displayable control characters, represented as
follows:
CrLF = carriage return and line feed
Gs = ASCII 29 (decimal)
Rs = ASCII 30 (decimal)
Eot = ASCII 4 (decimal)
! 0 100 570 1
PITCH 200
BARCODE UPS 0 0 2 CrLF[)>Rs01Gs96841706672
Gs 001Gs1Z12345675GsUPSNGs12345EGs089GsGs
1/1Gs10.1GsYGsGsGsUTRsEot
END
This example codes the following data:
[)>Rs Message Header
01Gs96 Transportation Data
Format Header
50 Revision F, January 2012, CognitiveTPG
