CognitiveTPG DLXi - Manual (Page 281)

E T H E R N E T P R I N T E R I N F O R M A T I O N
Manual Configuration
To send configuration data to the printer manually:
Connect the printer to a PC or terminal via a USB cable, or use the
optional cables to connect to a RS-232 or Centronics parallel port.
Send a configuration file containing the appropriate VARIABLE
commands to the printer.
You may disconnect the USB, serial, or parallel port and connect the
printer to your network after sending the configuration data to the
printer. A sample configuration file follows:
! 0 0 0 0
V ETHERNET IP 130.10.50.105
V ETHERNET NETMASK 255.255.0.0
V ETHERNET GATEWAY 130.10.250.1
V WRITE
V ETHERNET RESET
END
The new configuration settings will not take effect until you reset the
printer. In the above example, the VARIABLE ETHERNET RESET
command resets the printer. Turning the printer off and on will also
reset the printer and enable the new settings.
272 Revision F, January 2012, CognitiveTPG
