S T A N D A R D P R I N T E R C O M M A N D S
BARCODE PDF417
Function Prints a two-dimensional bar code on a label, using
the PDF417 symbology.
Explicit Form BARCODE PDF417 x y w:h ec% rows:cols
bytes T M data
Implicit Form BARCODE 7 x y w:h ec% rows:cols bytes T
M data
R Optional. Indicates rotated code
x y X and Y starting position for bar code
block.
w Width (x dimension) of the narrowest
element (bar or space) in the bar code.
h
Height (y dimension) of the shortest
element (bar or space) in the bar code.
: Optional. When used, indicates that w
and h define aspect ratio rather than
absolute size in dots.
ec Error correction level; 0 through 8.
%
Optional; indicates the error correction
level is expressed as the percentage of
code words in the bar code that are
devoted to error correction.
rows Number of bar code rows, from 3 to 90.
Entering 0 will cause the printer to
calculate the number of rows.
:
Optional. When used, indicates that rows
and cols define the overall symbol
aspect ratio rather than absolute number
of rows or columns.
Parameters
cols Number of bar code columns, from 1 to
30. Entering 0 will cause the printer to
calculate the number of columns.
Revision F, January 2012, CognitiveTPG 41
