19

463X Chlorine System Manual

Relay2 Rng: pH
0.00 14.0

>

Enter the range where Relay 2 will activate above and below this setpoint.

Relay2 PlsRate:
120 pulses/min

>

Set the maximum pulse rate. Range: 1–400 pulses/min.

If Pulse Mode was chosen:

Find New
Sensor(s):

>

Required only when a new sensor is changed while the power is on. Choose Yes or No.

Last Cal
10-18-09

>

Edit the calibration date.

End of Calibrate Menu

Relay 2 Rng: ppm
0.00 5.00

>

Enter the range where Relay 2 will activate above and below this setpoint.

Relay 2 Hys:
0.20 ppm

>

This relay will be deactivated at Relay 2 Range setpoints ± this hysteresis.

Relay 2 Delay:
0.0 secs

>

Set the time delay for Relay 2 to activate after reaching the setpoints set in the
Relay 2 Range.

If Window Mode was chosen:

Relay 2 Source:
pH

>

Choose pH or chlorine for Relay 2.

Relay 2 Source:
pH

>

Choose pH or chlorine for Relay 2.

8630 Calibrate Menu

8630 Calibrate Menu - continued
