13

463X Chlorine System Manual

IN

OUT

pH

Cl

OK

Flow Rate

The À ow rate is in the proper range when the À oat is
between the Min. and Max. markers on the À ow cell. The
À ow range limits are 30.24 to 45.36 L/h (8 to 12 gal/h).

Use suitable 9.5 mm (3/8 in) ID tubing that is rated for your
inlet pressure. Use hose clamps.

Valve position for start up and normal use.

Note: Turn off inlet valve ¿ rst when stopping water À ow.

• The drain tube must be positioned lower than the inÀ uent

water source to allow proper À ow through the À ow cell.
The À ow cell must drain by gravity, not system pressure.

• When testing, allow the sample to À ow for a few seconds

before collection.

Inlet Quick Release Connection

Press down gray plunger to release. Water À ow is
automatically shut off when disconnected.

For Low Flow applications (À ow less than 1 bar/15 psi), the
Flow Regulator can be removed and the À ow adjusted using
the Flow Cell ball valve. (NOTE: The inlet hose barb will also
need to be changed. Contact factory for details.)

Inlet

Drain

(to atmosphere)

Sampling port

(À ow off)

Water Flow

Tubing Connections

Water Flow
