Preliminary, Pr ogramming and contr ol, cont’d – Extron Electronics MGP 462xi Series User Manual
Page 82

SIS
™
Pr
ogramming and Contr
ol, cont’d
MGP Series • Softwar
e Configuration and Contr
ol
4-30
PRELIMINARY
Command/response table for IP SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
URL Encoded (Web)
(host to processor)
Response
(Processor to host)
Additional description
Information requests (continued)
Request system memory usage
3I
3I
n
bytes used out of n kBytes
]
Show amount of memory used and total
available memory for system operations.
With tagged response – verbose modes 2 and 3:
Inf03 * n bytes used out of n kBytes
]
Request user memory usage
4I
4I
n
bytes used out of n kBytes
]
Show amount of user memory used and total
available user memory.
With tagged response – verbose modes 2 and 3:
Inf04 * n bytes used out of n kBytes
]
Event control
Read event buffer memory
27
E X3%
,
X3^
,
X3&
,
X3*
E
}
W
X3%
,
X3^
,
X3&
,
X3*
E
|
X5$
]
Read the contents of a specific section of a
memory buffer for event number
X3%
.
X3%
= event number, 1 through 99.
X3^
= event buffer. For
X3^
: 0 = receive
1 = user
2 = NVRAM
X3&
= event buffer offset, 0 to maximum
buffer size.
X3*
= Event data size. For
X3*
:
b = bit
B = byte (8 bits)
S = short (16 bits)
L = long (32 bits)
X5$
= data element value in ASCII from
event buffer (leading zeros suppressed).
Write event to memory buffer
24 27
E X3%
,
X3^
,
X3&
,
X3(
,
X3*
E
}
W
X3%
,
X3^
,
X3&
,
X3(
,
X3*
E
|
Ewr
X3%
,
X3(
]
Write event
X3%
to buffer
X3^
, offset by
X3&
.
Include data
X3(
, size
X3*
.
X3(
= event data to write.
