Command/response table for SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
Response
(processor to host)
Additional description
DVI Input EDID/DDC (resolution and refresh rate) (continued)
View input 41# X50* * X51% ] View the DVI input EDID resolution/refresh rate.
Window blanking (muting)
Mute window X50@ * 1B X50@ Blk1 ] Blank (mute) window(s) X50@ using a selected
transition effect.
X50@ = 0 through 4; 0 = all windows.
Unmute window X50@ * 0B X50@ Blk0 ] Display (unmute) window(s) X50@ using a selected
transition effect.
View blanking status X50@ B X% ] View the window blanking status: 0 = off; 1 = on.
Window priority
Set priority X50@ * X50@ * X50@ * X50@ ~ Pri X50@ X50@ X50@ X50@ ] Set the priority of the windows to the order entered.
View priority ~ X50@ X50@ X50@ X50@ ] Display the priorities of the windows.
Window transition effect
Select effect 4 * X51! # Eff X51! ] Select window mute/unmute effect X51! .
For X51! :
1 = Cut 12 = Soft wipe curtain out
2 = Dissolve 13 = Hard wipe up
3 = Soft wipe up 14 = Hard wipe down
4 = Soft wipe down 15 = Hard wipe right
5 = Soft wipe right 16 = Hard wipe left
6 = Soft wipe left 17 = Hard wipe center in
7 = Soft wipe center in 18 = Hard wipe center out
8 = Soft wipe center out 19 = Hard wipe square in
9 = Soft wipe square in 20 = Hard wipe sq. out
10 = Soft wipe sq. out 21 = Hard wipe curtain in
11 = Soft wipe curtain in 22 = Hard wipe curt. out
View effect 4 # X51! ] View the currently selected mute/unmute effect.
Window effect duration
Select duration 5 * X51* # Dur X51* ] Set the speed of the window effect to X51* .
X51* = 0 to 5 seconds in 0.1-second increments
View duration 5# X51* ] View the effect duration time.
