Command/response table for SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
Response
(processor to host)
Additional description
Active lines
Specific value
13 *
X50)
*
X51&
#
Aln
X50)
*
X51&
]
Set the active lines value for the input
X50)
to
X51&
.
X50)
= 1 through 19.
X51&
= Auto-sensed value ± 512 lines or pixels.
Increment active lines value
13 *
X50)
+ #
Aln
X50)
*
X51&
]
Select the next higher active lines value.
Decrement active lines value
13 *
X50)
– #
Aln
X50)
*
X51&
]
Select the next lower active lines value.
View active lines setting
13 *
X50)
#
X51&
]
View the current active lines setting for input
X50)
.
Output scaler resolution and rate
Set output resolution and scan rate
X50*
*
X51%
=
Rte
X50*
*
X51%
]
Select a scaler output resolution and scan rate.
X50*
= scaler resolution. For
X50*
:
1 = 640x480 14 = 1600x1200
2 = 800x600 15 = 480p
3 = 852x480 16 = 576p
4 = 1024x768 17 = 720p
5 = 1024x852 18 = 1080i
6 = 1024x1024 19 = 1080p
7 = 1280x768 20 = DVI background input resol
8 = 1280x1024 21 = 1280x800
9 = 1360x765 22 = 1360x768
10 = 1365x768 23 = 1440x900
11 = 1366x768 24 = 1680x1050
12 = 1365x1024 25 = 1080p Sharp
13 = 1400x1050 26 = 1920x1200
X51%
= scaler refresh rate. For
X51%
:
1 = 50 Hz 6 = 120 Hz
2 = 60 Hz 7 = DVI background input refresh rate
3 = 72 Hz 8 = 24 Hz
4 = 96 Hz 9 = 59.94 Hz
5 = 100 Hz
View output rate settings
=
X50*
*
X51%
]
View the current output's resolution
X50*
and
refresh rate
X51%
settings.
View output rate details
0 =
width
* height * refresh rate
]
View the current output's resolution and refresh
rate in actual numbers.
N
The output rate detail command can display the actual resolution of the output when the MGP is configured to use the DVI background rate.
Example
0 =
1024*0768*060
The output resolution is 1024x768; the rate is 60 Hz.
