SIS
™
Pr
ogramming and Contr
ol, cont’d
MGP Series • Softwar
e Configuration and Contr
ol
4-22
PRELIMINARY
Command/response table for SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
Response
(processor to host)
Additional description
Special functions
Output polarity
1 *
X\
#
Pol
X\
]
Set output polarity. For
X\
:
0 = H-/V- (default)
1 = H-/V+
2 = H+/V-
3 = H+/V+
Example:
1 * 2 #
Pol 2
]
H+/V– sync polarity
View output polarity
1 #
X\
]
View the current output polarity setting.
Output sync format
2 *
X\
#
Syn
X\
]
Set the output sync format. For
X\
:
1 = RGBHV
2 = RGBS
3 = RGsB
4 = YUV bi-level
5 = YUV tri-level
View output sync format
2 #
X\
]
View the current output sync format setting.
Blue mode
3 *
X%
#
Blu
X%
]
Turn blue mode on and off. For
X%
:
1 = blue mode on; 0 = blue mode off.
View blue mode status
3 #
X%
]
View the current blue mode status.
Text position
6 *
X50@
*
X50%
#
X50@
Tlc
X50%
]
Change the location of the text label to
X50%
in
window
X50@
.
X50@
= 0 through 4; 0 = all windows.
For
X50%
:
0 = None 4 = Top left
1 = Bottom left 5 = Top center
2 = Bottom center 6 = Top right
3 = Bottom right
View text position
6 *
X50@
#
X50%
]
View the text label position in window
X50@
.
Text size
10 *
X\
#
Tsz
X\
]
Set the size of the label text. For
X\
:
1 = Small
2 = Medium
3 = Large
View text size
10 #
X\
]
View the current size of the label text.
