SIS
™
Pr
ogramming and Contr
ol, cont’d
MGP Series • Softwar
e Configuration and Contr
ol
4-10
PRELIMINARY
Command/response table for SIS commands (continued)
Command/response table for SIS commands
Command
ASCII (Telnet)
(host to processor)
Response
(processor to host)
Additional description
Input selection
Select an input
X50)
*
X50@
!
Out
X50@
• In
X50)
]
Set input source
X50)
to window
X50@
.
View input EDID/DDC
X50@
!
X50)
]
View the input channel for the selected window.
X50)
= 1 through 19.
X50@
= 0 through 4; 0 = all windows.
Input video type
Set video type
X50)
*
X50#
\
X50)
Typ
X50#
]
Set input
X50)
to format
X50#
.
View video type
X50)
\
X50#
]
View video signal type for input
X50)
.
For
X50#
:
1 = RGB 5 = S-video
2 = YUV-HD 6 = Composite video
3 = RGBcvS 7 = DVI or HD-SDI
4 = YUVi
N
It is recommended that virtual inputs be configured using the Windows-based control software. Refer to the software help file for the procedure.
DVI Input EDID/DDC (resolution and refresh rate)
Set EDID information
41 *
X50*
*
X51%
#
DDC
X50*
*
X51%
]
Set the DVI input EDID resolution to
X50*
and the
refresh rate to
X51%
.
X50*
= the scaler resolution. For
X50*
:
1 = 640x480 14 = 1600x1200
2 = 800x600 15 = 480p
3 = 852x480 16 = 576p
4 = 1024x768 17 = 720p
5 = 1024x852 18 = 1080i
6 = 1024x1024 19 = 1080p
7 = 1280x768 20 = DVI background input resol.
8 = 1280x1024 21 = 1280x800
9 = 1360x765 22 = 1360x768
10 = 1365x768 23 = 1440x900
11 = 1366x768 24 = 1680x1050
12 = 1365x1024 25 = 1080p Sharp
13 = 1400x1050 26 = 1920x1200
For
X51%
:
1 = 50 Hz 6 = 120 Hz
2 = 60 Hz 7 = DVI background refresh rate
3 = 72 Hz 8 = 24 Hz
4 = 96 Hz 9 = 59.94 Hz
5 = 100 Hz
N
The default state is to match the output resolution:
X50*
= 0;
X51%
= 0.
