SIS
™ Pr
ogramming and Contr
ol, cont’d
MGP Series • Softwar
e Configuration and Contr
ol
4-20
PRELIMINARY
Command/response table for SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
Response
(processor to host)
Additional description
Freeze
Enable freeze X50@ * 1 F X50@ Frz 1 ] Freeze the output video image in window X50@ .
X50@ = 0 through 4; 0 = all windows.
Disable freeze X50@ * 0 F X50@ Frz 0 ] Unfreeze the output image.
View freeze status X50@ F X% ] View the freeze status.
For
X% : 1 = frozen; 0 = not frozen.
Test pattern
Set test pattern X50$ J Tst X50$ ] Select test pattern X50$ . For X50$ :
0 = Off (none) 8 = Crop
1 = Color Bars 9 = Side By Side (4x3 crop)
2 = X-hatch (16x12) 10 = Quad Split (4x4)
3 = 4x4 H-hatch 11 = Pip Images (4x3 or 6x9
4 = Grey scale PIP col.)
5 = Ramp 12 = 1.78 Aspect (4x3/16x9)
6 = Alt. pixels 13 = 1.85 Aspect (4x3/16x9)
7 = White field 14 = 2.35 Aspect (4x3/16x9)
N Patterns #10 and 11 are not available on
the MGP 462xi models.
View test pattern J X50$ ] View the currently selected test pattern.
Executive mode
Enable executive mode 1X Exe 1 ] Lock front panel control except for the input
buttons; allow RS-232/422 and Ethernet control.
Enable executive mode 2 2X Exe 2 ] Lock all front panel controls including input
buttons; allow RS-232/422 and Ethernet control.
Disable executive mode 0X Exe 0 ] Unlock all front panel controls.
View executive mode status X 0 ] / 1 ] / 2 ] View executive mode status.
