SIS
™
Pr
ogramming and Contr
ol, cont’d
MGP Series • Softwar
e Configuration and Contr
ol
4-28
PRELIMINARY
Command/response table for IP SIS commands (continued)
Command
ASCII (Telnet)
(host to processor)
URL Encoded (Web)
(host to processor)
Response
(Processor to host)
Additional description
Ethernet data port
Set current connection port timeout
E
0 *
X6(
TC
}
W 0 %2A
X6(
TC
|
Pti 0 *
X6(
]
Set number of seconds (in tens of seconds)
before timeout on IP connections.
X6(
= 1 through 32767.
View current connection port timeout
E
0TC
}
W 0TC
|
X6(
]
Set global IP port timeout
E
1 *
X6(
TC
}
W 1 %2A
X6(
TC
|
Pti 1 *
X6(
]
View global port timeout
E
1TC
}
W 1TC
|
X6(
]
Firmware version requests
N
An asterisk (*) after the version number in these commands indicates which version is currently running. A caret (^) indicates bad checksum/invalid load. Question marks (?.??)
indicate that the firmware version is not loaded.
Query firmware version
Q or 1Q
Q
Q or 1Q
X1!
]
Show the MGP's firmware version number
X1!
to two decimal places. Gives the
number of the currently running version of
the user-updatable firmware.
With tagged response – verbose modes 2 and 3:
Ver01 *
X1!
]
Example:
1Q
1Q
1.01
Query verbose version information
0Q
0Q
Sum of responses from 2Q-3Q-4Q
]
Show bootstrap, factory-installed, and
updated firmware versions. (See 2Q, 3Q,
and 4Q, on the following lines.)
With tagged response – verbose modes 2 and 3:
Ver00 * Sum of responses from 2Q-3Q-4Q
]
Example:
0Q
0Q
1.00-0.00(1.48-MGP464 Series -Wed, 23 Jan 2003 18:37:59 GMT)-2.02*
(1.66-MGP464 Series -Wed, 17 Oct 2007 17:50:01 GMT)
Query bootstrap version
2Q
2Q
X1!
]
The bootstrap firmware is not user-
replaceable, but you may need this
information for troubleshooting.
With tagged response – verbose modes 2 and 3:
Ver02 *
X1!
]
Query factory firmware version
3Q
3Q
X1!
(plus web ver.-desc-UL date/time)
]
Factory-installed firmware is not user-
replaceable. This firmware was installed at
the factory; it is the version the processor
reverts to after a mode 1 reset (see chapter 3).
With tagged response – verbose modes 2 and 3:
Ver03 *
X1!
(plus web ver.-desc-UL date/time)
]
Example:
3Q
3Q
1.00(1.07-MGP464Series-Wed, 16 Jan 2006 03:28:10 GMT)
In this example, the factory firmware version
is 1.00, also known as the kernel version 1.07,
for the MGP 464, dated 16 January, 2006.
